OQ 65
OQ 65 is a fully automatic quick coupler system to suit all medium sized excavators from 15-24 t.
Why OQ?
- Change between various work tools within a few seconds!
- Increased versatility and efficiency.
- No oil spills, saving both money and the environment.
- No messy hose couplings.
- Saves the knees and back of the operator when unnecessary jumps in and out of the cab is avoided.
- The OilQuick system makes your excavator and your company more flexible, competitive, and cost effective.
- OilQuick is an advanced quick coupler system for excavators and can be supplied in various models for machines from 1 to 120 tons.
- Can distribute: Hydraulic oil, grease, water and electricity.
OQ 65
Imperial
Metric
| Max. output torque | 240 kNm |
| Bucket radius | 1,050 mm |
| Force at bucket edge | 230 kN |
| Width | 440 mm |
| Weight (approx) | 170 kg |
| Quick coupler with 2 parallel hydraulic cylinders | |
| Max. working pressure | 35 MPa |
| Load-bearing hose break valves | Yes |
| Pressure control valves | Yes |
| Leak-free quick couplers made of steel, OilQuick | |||
| Coupling sizes | 1/2" | 3/4" | 1" |
| Oil flow at 0.3 MPa pressure loss | 70 L/min | 140 L/min | 250 L/min |
| Max. continuous working pressure | 35 MPa | 35 MPa | 35 MPa |
| No. of couplings | 2 | 3 | - |
| Max. output torque | 177,010 Lb-ft |
| Bucket radius | 41.3" |
| Force at bucket edge | 51,710 Lb-ft |
| Width | 17.3" |
| Weight (approx) | 375 Lbs |
| Quick coupler with 2 parallel hydraulic cylinders | |
| Max. working pressure | 5,080 Psi |
| Load-bearing hose break valves | Yes |
| Pressure control valves | Yes |
| Leak-free quick couplers made of steel, OilQuick | |||
| Coupling sizes | 1/2" | 3/4" | 1" |
| Oil flow at 0.3 MPa pressure loss | 18 gal/min | 37 gal/min | 66 gal/min |
| Max. continuous working pressure | 5,080 Psi | 5,080 Psi | 5,080 Psi |
| No. of couplings | 2 | 3 | - |
OQ 65
Imperial
Metric
| Attachment frame for mechanical tools without coupling ramp | |
| Inside width | 440 mm |
| Pin distance | 530 mm |
| Pin diameter | 65 mm |
| Weight (approx) | 70 kg |
| Attachment frame for hydraulic tools with coupling ramp | |
| Inside width | 440 mm |
| Pin distance | 530 mm |
| Pin diameter | 65 mm |
| Weight (approx) | 90 kg |
| Hydraulic tool adapter plate with coupling ramp | |
| Inside width | 440 mm |
| Pin distance | 530 mm |
| Pin diameter | 65 mm |
| Weight (approx) | 210 kg |
| Hydraulic tool special adapter with coupling ramp | |
| Inside width | 440 mm |
| Pin distance | 530 mm |
| Pin diameter | 70 mm |
| Weight (approx) | See identification plate on adapter |
| Attachment frame for mechanical tools without coupling ramp | |
| Inside width | 17.3" |
| Pin distance | 20.9" |
| Pin diameter | 2.6" |
| Weight (approx) | 150 Lbs |
| Attachment frame for hydraulic tools with coupling ramp | |
| Inside width | 17.3" |
| Pin distance | 20.9" |
| Pin diameter | 2.6" |
| Weight (approx) | 200 Lbs |
| Hydraulic tool adapter plate with coupling ramp | |
| Inside width | 17.3" |
| Pin distance | 20.9" |
| Pin diameter | 2.6" |
| Weight (approx) | 460 Lbs |
| Hydraulic tool special adapter with coupling ramp | |
| Inside width | 17.3" |
| Pin distance | 20.9" |
| Pin diameter | 2.8" |
| Weight (approx) | See identification plate on adapter |
